GSMCentrum.CZ » Measuring instruments » Oscilloscopes
Scopemeter 20MHz colour,LCD TFT 5,7" (640x480) Ch 2 40Msps
| Barcode: | |
| Number: | TMEFLK-123B |
| Package: | |
| Min. quantity: | 1 |
| Availability | Only per order |
|---|---|
| Manufacturer: | FLUKE |
Scopemeter 20MHz colour,LCD TFT 5,7" (640x480) Ch 2 40Msps - Popis produktu
| Manufacturer | FLUKE |
|---|---|
| Type of oscilloscope | scopemeter |
| Band | 20MHz |
| Kind of display used | colour |
| Kind of display used | LCD TFT 5,7" (640x480) |
| Number of channels | 2 |
| Measurement | active power |
| Measurement | AC voltage |
| Measurement | apparent power |
| Measurement | capacitance |
| Measurement | DC voltage |
| Measurement | energy |
| Measurement | harmonics |
| Measurement | power factor |
| Measurement | reactive power |
| Measurement | resistance |
| Sampling | 40Msps |
| Time base | 20n...60s/div |
| DC voltage measuring range | 500mV |
| DC voltage measuring range | 5V |
| DC voltage measuring range | 50V |
| DC voltage measuring range | 500V |
| DC voltage measuring range | 750V |
| DC voltage measuring accuracy | ±(0,5% + 5 digits) |
| AC voltage measuring range | 500mV |
| AC voltage measuring range | 5V |
| AC voltage measuring range | 50V |
| AC voltage measuring range | 500V |
| AC voltage measuring range | 750V |
| Resistance measuring range | 500Ω |
| Resistance measuring range | 5kΩ |
| Resistance measuring range | 50kΩ |
| Resistance measuring range | 500kΩ |
| Resistance measuring range | 5MΩ |
| Resistance measuring range | 30MΩ |
| Resistance measuring accuracy | ±(0,6% + 5 digits) |
| Capacitance measuring range | 50nF |
| Capacitance measuring range | 500nF |
| Capacitance measuring range | 5µF |
| Capacitance measuring range | 50µF |
| Capacitance measuring range | 500µF |
| Test | 0.5mA @2.8V |
| Continuity test | acoustic indication |
| Additional functions | multimeter |
| Power supply | power supply 17,8V DC |
| Power supply | rechargeable battery Li-Ion 10,8V x1 |
| Plug variant | EU |
| Dimensions | 259x132x55mm |
| Weight | 1.4kg |
| Conform to the norm | EN61010 600V CAT IV |
| Conform to the norm | EN61010 750V CAT III |
| IP rating | IP51 |
| Measuring instrument features | 20 screens memory |
| Measuring instrument features | Connect-and-View function that ensures stable, reliable and repeatable signal display without operator |
| Measuring instrument features | IntellaSet™ technology automatically and intelligently adjusts numerical readout based on the measured signal |
| Measuring instrument features | rugged design to withstand 3g Vibration, 30g shock |
| Measuring instrument features | set actual value to reference |
| Measuring instrument features | WiFi adapter connected to internal USB port to wirelessly transfer information to the PC, laptop or Fluke Connect® mobile app |
| Measuring instrument features | zxternal optically isolated USB interface to transfer, archive and analyze scope or meter data |
| Standard equipment | 2 x shielded test lead with ground lead |
| Standard equipment | adaptor WiFi USB |
| Standard equipment | battery charger/power supply |
| Standard equipment | black test lead |
| Standard equipment | blue and red grapple hook |
| Standard equipment | BNC to banana plug adapter |
| Optional equipment | 240A AC/DC FLK-I200S current clamp probe |
| Optional equipment | 400A AC/DC FLK-I410 current clamp probe |
| Optional equipment | FLK-I310S - current clamp |
| Optional equipment | FLK-I400S - current clamp |
| Related items | POM-72941 |
| Related items | POM-72942 |
| Manufacturer series | FLUKE 120B |
| Battery/ rechargeable battery | rechargeable battery Li-Ion 10,8V x1 |
