GSMCentrum.CZ » Automation technology » Regulation and control » Regulators
Module regulator Pt100 temperature SPDT OUT 2 SPST-NO 0÷50°C
| Items in stock i | 1 pieces |
|---|---|
| Barcode: | |
| Number: | TMERE55-012100M0 |
| Package: | |
| Min. quantity: | 1 |
| Manufacturer: | LUMEL |
Popis produktu
Module regulator Pt100 temperature SPDT OUT 2 SPST-NO 0÷50°C - Popis produktu
| Manufacturer | LUMEL |
|---|---|
| Type of module | regulator |
| Kind of temperature sensor | Pt100 |
| Controlled parameter | temperature |
| Kind of output 1 | SPDT |
| Kind of output 2 | SPST-NO |
| Regulation for output 1 | PID |
| Mounting | on panel |
| Output 1 electrical parameters | 250V AC / 2A |
| Output 2 electrical parameters | 250V AC / 1A |
| Controlled parameter range | -50...100°C |
| Operating temperature | 0...50°C |
| Supply voltage | 85...253V AC |
| Supply voltage | 85...253V DC |
| The programming method | adjusting screw |
| Body dimensions | 96x96x65mm |
| Mounting hole diameter | 92.5x92.5mm |
| IP rating | IP20 at terminal side |
| IP rating | IP40 (from the front) |
| Input 1 properties | RTD |
| Kind of display used | 4-digit LED |
