| Availability | Only per order |
|---|---|
| Barcode: | |
| Number: | TMELIYY52X0.25 |
| Package: | |
| Min. quantity: | 1 |
| Manufacturer: | HELUKABEL |
HELUKABEL 18052 Wire TRONIC LiYY 52x0,25mm2 unshielded 500V Cu stranded grey - Popis produktu
| Manufacturer | HELUKABEL |
|---|---|
| Type of wire | data transmission |
| Kind of wire | TRONIC LiYY |
| Shield structure | unshielded |
| Rated voltage | 500V |
| Wire insulation material | PVC |
| Kind of core | Cu |
| Core structure | stranded |
| Number of cores | 52 |
| Core section | 0.25mm2 |
| Core marking | colours without colour repetition |
| Insulation colour | grey |
| Cable external diameter | 13.3mm |
| Operating temperature | -40...80°C |
| Resistance to | most of chemical compounds |
| Resistance to | most of oils |
| Earth core | none |
| CPR standard | Eca |
| Cable features | no flame propagation |
