Digital multimeter LCD 5 digits (60000) True RMS AC+DC IP67
| Barcode: | |
| Number: | TMEU1282A |
| Package: | |
| Min. quantity: | 1 |
| Items in stock i | 5 pieces |
|---|---|
| Manufacturer: | KEYSIGHT TECHNOLOGIES |
Digital multimeter LCD 5 digits (60000) True RMS AC+DC IP67 - Popis produktu
| Manufacturer | KEYSIGHT TECHNOLOGIES |
|---|---|
| Type of meter | digital multimeter |
| Measurement | AC current |
| Measurement | AC voltage |
| Measurement | capacitance |
| Measurement | DC current |
| Measurement | DC voltage |
| Measurement | frequency |
| Measurement | resistance |
| Kind of display used | LCD 5 digits (60000) |
| DC voltage measuring range | 60mV |
| DC voltage measuring range | 600mV |
| DC voltage measuring range | 6V |
| DC voltage measuring range | 60V |
| DC voltage measuring range | 600V |
| DC voltage measuring range | 1kV |
| DC voltage measuring accuracy | ±(0,025% + 5 digits) |
| AC voltage measuring range | 60mV |
| AC voltage measuring range | 600mV |
| AC voltage measuring range | 6V |
| AC voltage measuring range | 60V |
| AC voltage measuring range | 600V |
| AC voltage measuring range | 1kV |
| AC voltage measuring accuracy | ±(0,3% + 25 digits) |
| Bandwidth for AC voltage measurements | 20Hz...100kHz |
| DC current measuring range | 600µA |
| DC current measuring range | 6000µA |
| DC current measuring range | 60mA |
| DC current measuring range | 600mA |
| DC current measuring range | 6A |
| DC current measuring range | 10A |
| AC current measuring range | 600µA |
| AC current measuring range | 6000µA |
| AC current measuring range | 60mA |
| AC current measuring range | 600mA |
| AC current measuring range | 6A |
| AC current measuring range | 10A |
| DC current measuring accuracy | ±(0,05% + 5 digits) |
| AC current measuring accuracy | ±(0,6% + 25 digits) |
| Bandwidth for AC current measurements | 20Hz...100kHz |
| True effective value measurement | True RMS AC+DC |
| Resistance measuring range | 60Ω |
| Resistance measuring range | 600Ω |
| Resistance measuring range | 6kΩ |
| Resistance measuring range | 60kΩ |
| Resistance measuring range | 600kΩ |
| Resistance measuring range | 6MΩ |
| Resistance measuring range | 60MΩ |
| Resistance measuring range | 600MΩ |
| Resistance measuring accuracy | ±(0,05% + 2 digits) |
| Capacitance measuring range | 10nF |
| Capacitance measuring range | 100nF |
| Capacitance measuring range | 1µF |
| Capacitance measuring range | 10µF |
| Capacitance measuring range | 100µF |
| Capacitance measuring range | 1mF |
| Capacitance measuring range | 10mF |
| Capacitance measuring range | 100mF |
| Capacitance measuring accuracy | ±(1% + 5 digits) |
| Frequency measuring range | 99.999...9.9999MHz |
| Frequency measuring accuracy | ±(0,005% + 3 digits) |
| Diode test | 1.7mA |
| IP rating | IP67 |
| Weight with battery | 701g |
| Power supply | 4 batteries 1,5V LR6 (AA) |
| Standard equipment | batteries |
| Standard equipment | IR-USB cable |
| Standard equipment | manufacturer's calibration certificate |
| Standard equipment | test leads |
| Standard equipment | user's manual |
| Conform to the norm | EN61010 600V CAT IV |
| Conform to the norm | EN61010 1000V CAT III |
| Dimensions (W x H x D) | 96x218x59mm |
| Information | Products are intended for professional and industrial use only, and are not suitable for consumer or household use. |
| Series | U1280 |
