GSMCentrum.CZ » Measuring instruments » Multimeters, measuring instruments » Testers for electrical installations
Meter multifunction digital,pincers type Øcable 57mm LCD
| Items in stock i | 2 pieces |
|---|---|
| Barcode: | |
| Number: | CMP-2000 |
| Package: | |
| Min. quantity: | 1 |
| Manufacturer: | SONEL |
Popis produktu
Meter multifunction digital,pincers type Øcable 57mm LCD - Popis produktu
| Manufacturer | SONEL |
|---|---|
| Type of meter | multifunction |
| Kind of meter | digital |
| Kind of meter | pincers type |
| Max. diameter of measured cable | 57mm |
| Kind of display used | LCD |
| Display parameters | (6000) |
| DC current measuring range | 659.9A |
| DC current measuring range | 2kA |
| AC current measuring range | 659.9A |
| AC current measuring range | 1.5kA |
| Measuring instrument features | automatic power-off |
| Measuring instrument features | HOLD function |
| Measuring instrument features | InRush function |
| Measuring instrument features | MAX function |
| Measuring instrument features | pocket size |
| Measuring instrument features | reinforced enclosure |
| DC current measuring accuracy | ±(2% + 5 digit) |
| AC current measuring accuracy | ±(2% + 10 digit) |
| DC voltage measuring range | 6.599V |
| DC voltage measuring range | 65.99V |
| DC voltage measuring range | 659.9V |
| DC voltage measuring range | 1kV |
| DC voltage measuring accuracy | ±(0.5% + 2 digit) |
| AC voltage measuring range | 6.599V |
| AC voltage measuring range | 65.99V |
| AC voltage measuring range | 659.9V |
| AC voltage measuring range | 750V |
| AC voltage measuring accuracy | ±(1.5% + 8 digit) |
| Resistance measuring accuracy | ±(1%+5 digit) |
| True effective value measurement | True RMS AC+DC |
| Resistance measuring range | 659.9Ω |
| Resistance measuring range | 6.599kΩ |
| Resistance measuring range | 65.99kΩ |
| Resistance measuring range | 659.9kΩ |
| Resistance measuring range | 6.59MΩ |
| Resistance measuring range | 66MΩ |
| Capacitance measuring range | 6.599nF |
| Capacitance measuring range | 65.99nF |
| Capacitance measuring range | 659.9nF |
| Capacitance measuring range | 6.599µF |
| Capacitance measuring range | 65.99µF |
| Capacitance measuring range | 659.9µF |
| Capacitance measuring range | 6599µF |
| Capacitance measuring accuracy | ±(3%+ 10 digit) |
| Frequency measuring range | 65.99Hz |
| Frequency measuring range | 659.9Hz |
| Frequency measuring range | 6.599kHz |
| Frequency measuring range | 65.99kHz |
| Frequency measuring range | 659.9kHz |
| Frequency measuring range | 1MHz |
| Frequency measuring accuracy | ±(0.1%+5 digit) |
| Test | diodes |
| Body dimensions | 281x108x53mm |
| Weight with battery | 570g |
| Power supply | battery 6LR61 9V x1 |
| Standard equipment | calibration certificate |
| Standard equipment | case |
| Standard equipment | drop-like K-type probe |
| Standard equipment | test leads |
| Measurement | AC current |
| Measurement | AC voltage |
| Measurement | capacitance |
| Measurement | DC current |
| Measurement | DC voltage |
| Measurement | frequency |
| Measurement | inrush current |
| Measurement | resistance |
| Measurement | temperature |
| Conform to the norm | CAT III 1000V |
| Conform to the norm | CAT IV 600V |
| Conform to the norm | EN 61010 |
| IP rating | IP20 |
| Battery/ rechargeable battery | battery 6LR61 9V x1 |
| Continuity test | <30Ω |
| Illumination | yes |
| Bargraph | yes |
